Michael James Wahl

US Patent:

6568836, May 27, 2003

Filed:

Sep 19, 2001

Appl. No.:

09/955878

Inventors:

Michael Wahl - Troy OH

Assignee:

Midmark Corporation - Versailles OH

International Classification:

F21S 806

US Classification:

362404, 362418, 362371, 362804, 362285, 2482981, 248343

Abstract:

A track mounting system for supporting equipment, such as a dental light, includes a pan-shaped carriage which is suspended from the track mounting system and to which the light or other equipment is attached. The track mounting system includes a pair of spaced, parallel tracks which are engaged by rollers rotatably mounted on inner walls of the carriage. At least one of the rollers is formed from a relatively hard material and is concave to mate with the complementary surface on one of the tracks to provide resistance against side loads. Other rollers are formed from a relatively soft material and are convex to provide a light frictional resistance to movement of the carriage along the tracks that inhibits drift, over-travel and other inadvertent movement of the carriage, while reducing noise.

US Patent:

8029505, Oct 4, 2011

Filed:

Aug 25, 2005

Appl. No.:

11/213030

Inventors:

Jim Hearn - Coatsville PA, US
Thomas J. Maughan - Downingtown PA, US
Timothy J. Horan - Royersford PA, US
Michael J. Wahl - Wilmington DE, US

Assignee:

Synthes USA, LLC - West Chester PA

International Classification:

A61B 17/00

US Classification:

606 56, 606277, 606 59

Abstract:

An external fixation system for connecting one or more bone segments together to facilitate healing of bone. The system may include one or more rings and/or ring segments. One or more linear distractors and/or angular distractors may connect the rings to each other so as to allow for distraction and/or reduction/compression of a bone. Linear distractors may enable an operator to move the rings towards and away from each other, while angular distractors may enable an operator to angle the rings relative to each other. In an embodiment using angular distractors, one or more angular separation assemblies may be positioned between the rings. These separation assemblies may have joints which may two portions which may be angled relative to each other and connected directly or indirectly to the rings. Various fasteners (e. g. , nuts) and/or tightening members may configured for quick movement along and selective tightening to various components.

US Patent:

20220304735, Sep 29, 2022

Filed:

Jun 14, 2022

Appl. No.:

17/840345

Inventors:

- Raynham MA, US
Michael WAHL - West Chester PA, US

International Classification:

A61B 17/88
A61B 17/86

Abstract:

A cylindrical shaft may be gripped with an apparatus including a housing having an axis and an inner surface with multiple asymmetric cam surfaces, a proximal end including a means to rotate the housing, and a distal end having an opening configured to receive the cylindrical shaft, at least two cylindrical gripping members configured to grip the cylindrical shaft, where each cylindrical gripping member contacts a corresponding asymmetric cam surface at a first rest position, and a rotatable frame which holds each pair of cylindrical gripping members at a fixed angular orientation relative to each other. The rotatable frame is configured to rotate upon insertion of the cylindrical shaft into a space defined by the gripping members so that each gripping member moves away from the axis of the housing along a first portion of the corresponding asymmetric cam surface. After insertion of the cylindrical shaft, the housing is configured to rotate so as to cause each gripping member to move toward the axis of the housing along the corresponding asymmetric cam surface.

US Patent:

20220202492, Jun 30, 2022

Filed:

Dec 30, 2020

Appl. No.:

17/138461

Inventors:

- Raynham MA, US
Michael WAHL - West Chester PA, US
Bernd GUTMAN - Hassloch, DE
Charlton VAUGH - Ladenberg PA, US
Albert MONTELLO - Berwyn PA, US

International Classification:

A61B 34/10
A61B 17/62
A61B 34/00

Abstract:

A computer-implemented method for producing a treatment plan to control manipulation of a fixation apparatus including a first element and a second ring and struts to correct an anatomical structure deformity of first and second anatomical structure segments, including: receiving, using one or more graphical user interfaces of a computing system, configuration information associated with the fixation apparatus, the configuration information comprising one or more geometric characteristics of one or more elements of the fixation apparatus and ring deformation information; receiving, by the computing system, images of the fixation apparatus and the first and the second anatomical structure segments attached thereto; determining, by the computing system, based on the configuration information and the received images, positions and orientations of the first and the second anatomical structure segments in three-dimensional space relative to the fixation apparatus; determining the hole locations of the first element based upon the deformation information; determining, by the computing system, manipulations to the fixation apparatus for correction of the anatomical structure deformity, the manipulations comprising adjustments to the struts based upon the determined hole location of the first element; and providing, by the computing system, to one or more users, indications of the manipulations to the fixation apparatus.

US Patent:

20210251676, Aug 19, 2021

Filed:

Feb 18, 2020

Appl. No.:

16/793725

Inventors:

- Raynham MA, US
Michael WAHL - West Chester PA, US

International Classification:

A61B 17/88
A61B 17/86

Abstract:

A cylindrical shaft may be gripped with an apparatus including a housing having an axis and an inner surface with multiple asymmetric cam surfaces, a proximal end including a means to rotate the housing, and a distal end having an opening configured to receive the cylindrical shaft, at least two cylindrical gripping members configured to grip the cylindrical shaft, where each cylindrical gripping member contacts a corresponding asymmetric cam surface at a first rest position, and a rotatable frame which holds each pair of cylindrical gripping members at a fixed angular orientation relative to each other. The rotatable frame is configured to rotate upon insertion of the cylindrical shaft into a space defined by the gripping members so that each gripping member moves away from the axis of the housing along a first portion of the corresponding asymmetric cam surface. After insertion of the cylindrical shaft, the housing is configured to rotate so as to cause each gripping member to move toward the axis of the housing along the corresponding asymmetric cam surface.

US Patent:

20200397480, Dec 24, 2020

Filed:

Jun 24, 2019

Appl. No.:

16/450527

Inventors:

- Raynham MA, US
Joseph COSTANZO - West Chester PA, US
Joseph PETERSON - Raynham MA, US
Michael WAHL - West Chester PA, US

International Classification:

A61B 17/64
A61B 17/62

Abstract:

A polyaxial external fixation strut including a strut member and a first ball joint coupled to an end portion of the strut member. The first ball joint includes a first ball joint body and a first ball member. The first ball member is rotatably coupled to the first ball joint body to allow for variable angle adjustable positioning of the first ball member within the first ball joint body. The first ball joint additionally includes a friction member. The friction member is configured to create friction between the first ball member and the first ball joint body.

US Patent:

20170238967, Aug 24, 2017

Filed:

May 9, 2017

Appl. No.:

15/590687

Inventors:

- Raynham MA, US
Michael Wahl - Wilmington DE, US
Thomas Joseph Maughan - Downingtown PA, US
Nicole Murray - West Milford NJ, US

International Classification:

A61B 17/62
A61B 17/64

Abstract:

The present application discloses embodiments related to an external bone fixation device configured to correct bone deformities or repair bone injuries. The device can include a plurality of bases configured to be attached to portions of a bone and a plurality of struts configured to be adjustable in length to change the position and orientation of the plurality of bases and the attached bone portions.

US Patent:

20160206356, Jul 21, 2016

Filed:

Jan 16, 2015

Appl. No.:

14/599419

Inventors:

- Raynham MA, US
Michael WAHL - West Chester PA, US
Rene HAAG - West Chester PA, US
Robert LIMOUZE - West Chester PA, US
George HAIDUKEWYCH - Orlando FL, US
Bruce H. ZIRAN - Atlanta GA, US
Cory A. COLLINGE - Fort Worth TX, US
Frank A. LIPORACE - Fort Lee NJ, US

International Classification:

A61B 17/80
A61B 17/72

Abstract:

A plate for treating a bone includes a plate body extending along a longitudinal axis from a first end to a second end and being sized, shaped and contoured to be positioned along a desired surface of a bone. The plate also includes a slotted opening extending through the plate body and defined by a first portion sized and shaped to permit a head portion of a bone fixation element fixed to the bone to be passed therethrough and a second elongated portion extending along the longitudinal axis from the first portion in communication with the first portion, the second portion sized to prevent the head portion of the bone fixation element from being passed therethrough so that, when the head portion of the bone fixation element is received through the first portion, the plate is slidable relative thereto such that the second portion engages the head portion of the bone fixation element.

Author:

Michael Wahl

ISBN #:

3527404422

Author:

Michael Iver Wahl

ISBN #:

0442291507
